1723101107

1723101107 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Molex. Its product description is CONN HEADER R/A 7POS 3.5MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for 1723101107

• Description：CONN HEADER R/A 7POS 3.5MM
• Series：Ultra-Fit 172310
• Mfr：Molex
• Package：Bulk
• Connector Type：Header
• Contact Type：Male Pin
• Pitch - Mating：0.138" (3.50mm)
• Number of Positions：7
• Number of Rows：1
• Row Spacing - Mating：-
• Number of Positions Loaded：All
• Style：Board to Cable/Wire
• Shrouding：Shrouded - 4 Wall
• Mounting Type：Through Hole, Right Angle
• Termination：Solder
• Fastening Type：Latch Holder
• Contact Length - Mating：-
• Contact Length - Post：0.126" (3.20mm)
• Overall Contact Length：-
• Insulation Height：0.353" (8.96mm)
• Contact Shape：Square
• Contact Finish - Mating：Tin
• Contact Finish Thickness - Mating：60.0µin (1.52µm)
• Contact Finish - Post：Tin
• Contact Material：Copper Alloy
• Insulation Material：Liquid Crystal Polymer (LCP)
• Features：Board Guide
• Operating Temperature：-40°C ~ 105°C
• Ingress Protection：-
• Material Flammability Rating：UL94 V-0
• Insulation Color：Black
• Current Rating (Amps)：-
• Voltage Rating：400V

Headers, Male Pins datasheet and documents for 1723101107
