Edgeboard Connectors Overview

The TE Connectivity AMP Connectors part number 1766354-1 is a dual-edge card edge connector designed for board-to-board applications. It features four positions with female contacts, utilizing a gold surface finish to ensure reliable signal transmission. The connector has a mating interface width of 0.098 inches (2.50mm). It is classified as an edgeboard connector and is currently in active production status.

Edgeboard Connectors Feature Summary

• Dual-edge configuration for secure board engagement
• Female contact type for mating compatibility
• Gold-plated contacts for corrosion resistance

Edgeboard Connectors Applications

• High-speed modular connector assemblies
• Backplane interconnection systems
• Edgeboard connectivity solutions

Edgeboard Connectors Procurement Notes

Verify the specific datasheet requirements before procurement to ensure compatibility with your PCB design parameters. Confirm that the dual-edge female configuration matches your system's mating hardware specifications. Check for any recent product change notices or lifecycle updates directly from the manufacturer to guarantee long-term availability and performance consistency.

Edgeboard Connectors Selection Notes

Select this component when a dual-edge female connector with four positions is required for high-speed or modular applications. Ensure the 0.098-inch (2.50mm) interface width aligns with your board thickness and routing constraints. Consider the gold contact plating for environments requiring enhanced durability against oxidation and frequent mating cycles compared to tin alternatives.

Edgeboard Connectors Part Context

This component belongs to the high-speed and modular connector category within the TE Connectivity AMP Connectors portfolio. It serves as an accessory for backplane and edgeboard systems, providing a robust mechanical and electrical interface. The part is distinct from single-edge connectors and is specifically engineered for dual-sided board engagement.

Edgeboard Connectors Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Verify compatibility with existing housing or mating components if considering alternative sources.
