1888946-2 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists TE Connectivity AMP Connectors. Its product description is CONN EDGE DUAL FMALE 6POS GOLD. Review the specifications below when checking this part for your BOM.
Edgeboard Connectors specifications for 1888946-2
- Description：CONN EDGE DUAL FMALE 6POS GOLD
- Series：SEC-II
- Mfr：TE Connectivity AMP Connectors
- Package：Bulk
- Card Type：Non Specified - Dual Edge
- Gender：Female
- Number of Positions/Bay/Row：-
- Number of Positions：6 (Power)
- Card Thickness：0.062" (1.57mm)
- Number of Rows：2
- Pitch：-
- Read Out：Dual
- Features：-
- Mounting Type：Through Hole
- Termination：Press-Fit
- Contact Material：Copper Alloy
- Contact Finish：Gold
- Contact Finish Thickness：15.0µin (0.38µm)
- Contact Type：-
- Color：Black
- Flange Feature：-
- Operating Temperature：-55°C ~ 105°C
Edgeboard Connectors datasheet and documents for 1888946-2
Edgeboard Connectors Overview
The TE Connectivity AMP Connectors part number 1888946-2 is a dual-edge female connector assembly designed for power applications. It features 6 positions with gold-plated contacts and a black housing. The component operates within a temperature range of -55°C to 105°C. It utilizes a dual-row configuration suitable for secure secondary power connections in demanding environments.
Edgeboard Connectors Feature Summary
- Dual-edge female contact design for secure board insertion
- Gold-plated contacts ensure reliable conductivity
- Black housing provides visual identification and insulation
Edgeboard Connectors Applications
- Secondary power distribution in industrial equipment
- Power supply interconnections in server hardware
- Embedded systems requiring robust power connectors
Edgeboard Connectors Procurement Notes
Verify the specific datasheet revision and mechanical drawings before integration. Confirm that the mating edge card thickness matches the connector's retention requirements. Ensure environmental conditions remain within the specified -55°C to 105°C operating range for long-term reliability.
Edgeboard Connectors Selection Notes
Select this component when a low-profile, dual-edge female connector is required for secondary power paths. The gold plating offers superior corrosion resistance compared to tin variants. Consider the 6-position count and dual-row layout for space-constrained power delivery designs.
Edgeboard Connectors Part Context
This part belongs to the AMP Connectors family, known for ruggedized solutions developed since 1941. The series emphasizes reliable press-fit and edge-card technologies for harsh environments. It represents TE Connectivity's legacy in providing secure interconnects for aerospace, marine, and industrial sectors.
Edgeboard Connectors Replacement Considerations
Check for direct substitutes within the same AMP series offering identical pin counts and dual-edge form factors. Verify compatibility with existing PCB footprints and mating edge cards before substitution.
