1926088-2

Edgeboard Connectors Overview

The TE Connectivity AMP Connectors model 1926088-2 is a high-current board-to-board interconnect component belonging to the CRWN series. It features a vertical mounting configuration with dual edge contacts designed for robust power distribution in electronic assemblies. The connector provides 30 positions with a 1.50mm (0.059 inch) pitch, accommodating significant current loads. Constructed with copper alloy contacts and gold plating, it ensures reliable electrical performance. The housing is black, UL94 V-0 rated plastic, suitable for demanding industrial environments requiring stable board-to-board connections.

Edgeboard Connectors Feature Summary

• Vertical dual-edge contact design for secure board-to-board mating
• High current capacity supporting substantial power distribution requirements
• Gold-plated copper alloy contacts for enhanced conductivity and corrosion resistance
• UL94 V-0 flame retardant housing material for safety compliance

Edgeboard Connectors Applications

• Industrial control systems requiring high-power board interconnects
• Telecommunications infrastructure equipment
• Automotive electronics modules
• Power supply units and converters

Edgeboard Connectors Procurement Notes

Verify the specific pin count and pitch against your PCB footprint before ordering. Confirm that the vertical orientation matches your assembly constraints. Ensure the mating board thickness aligns with the connector's design specifications. Check for any updated environmental compliance certifications required by your region. Validate that the current rating meets the maximum load of your circuit design.

Edgeboard Connectors Selection Notes

Choose this component when high current carrying capability is critical for board-to-board links. The dual-edge contact system offers stability compared to single-edge alternatives. Consider the vertical profile for space-constrained enclosures. Verify compatibility with mating connectors in the same series. Evaluate thermal management needs given the high current ratings associated with this form factor.

Edgeboard Connectors Part Context

This part belongs to the CRWN series of edgeboard connectors from TE Connectivity. These connectors are engineered for applications demanding high reliability and current handling. The series typically includes various pin counts and configurations to suit different power distribution needs. They are widely used in industries where stable, high-current connections between circuit boards are essential for system operation.

Edgeboard Connectors Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Consult TE Connectivity technical support for direct replacements or obsolescence management options.
