1EB3

Overview

The TE Connectivity Corcom Filters 1EB3 is a single-phase EMC/EMI line filter designed for general-purpose applications. It operates at a rated voltage of 250 VAC and supports a current rating of 1 A. The unit utilizes wire lead input and output connections, facilitating direct wiring integration. It features a chassis mount configuration and employs a single-stage filtering architecture. The component functions within a frequency range of 50/60 Hz and meets low leakage current requirements specified by VDE standards.

Feature Summary

• Single-stage EMI/RFI filtering architecture
• Wire lead input and output termination
• Chassis mount installation style
• Compliance with VDE low leakage current standards

Applications

• High impedance loads at low current
• General purpose power line filtering
• Equipment requiring single-phase EMI suppression

Procurement Notes

Verify the specific datasheet version for the 1EB3 part number to confirm current manufacturing status and exact dimensional drawings. Ensure that the wire lead specifications match the target assembly requirements. Cross-reference the internal TE number 6609020-2 for accurate identification in procurement systems. Confirm compliance certifications required for the final destination market before ordering.

Selection Notes

Select this component when a single-stage filter is sufficient for the application's noise reduction needs. The 1 A current rating and 250 VAC voltage limit define the operational boundaries. Consider the wire lead termination style if panel mounting hardware or PCB connectors are not preferred. Verify that the chassis mount form factor fits the available enclosure space.

Part Context

This component belongs to the Corcom B series of single-phase filters from TE Connectivity. The series focuses on general-purpose RFI filtration for electronic equipment. The 1EB3 variant specifically addresses low-current applications where minimal leakage current is critical. It serves as a fundamental building block for power entry modules in various industrial and commercial devices.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
