1EZP

Overview

The TE Connectivity Corcom Filters 1EZP is a single-phase EMC/EMI line filter module designed for AC power line applications. It operates at a rated voltage of 250VAC and supports a current capacity of 1A at 50/60Hz. The component utilizes a single-stage filtering configuration to suppress electromagnetic interference. It features through-hole termination with PC pins for circuit board mounting. The unit is classified as a general-purpose filter suitable for commercial equipment requiring noise reduction in power inputs.

Feature Summary

• Single-stage EMI/RFI filtering architecture
• Through-hole PC pin termination style
• Integrated voltage selector capability

Applications

• General purpose AC power line filtering
• Commercial electronic equipment noise suppression
• Single-phase power input protection

Procurement Notes

Verify the obsolete status of this part number before procurement planning. Confirm availability through authorized distributors or surplus channels. Ensure replacement components match the original electrical ratings and physical dimensions. Check for updated datasheets regarding any design changes or end-of-life notices from the manufacturer.

Selection Notes

Select this component for applications requiring single-phase EMI suppression at 1A and 250VAC. Verify that the single-stage attenuation meets system noise requirements. Ensure the PCB layout accommodates the PC pin spacing and axial form factor. Consider thermal derating if operating near maximum current limits in enclosed environments.

Part Context

This module belongs to the TE Connectivity Corcom Filters series, which specializes in power line filters for industrial and commercial electronics. The 1EZP variant represents a basic single-stage solution within the broader portfolio of EMI/RFI mitigation products offered by the manufacturer for AC power applications.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Due to the obsolete status, verify compatibility with alternative single-stage 1A 250VAC filters from the same manufacturer or other suppliers.
