Product Detailed Parameters
- Description：DC-DC INDUSTRIAL
- Series：1T10A2_1.5UP (1W)
- Mfr：GAPTEC Electronic
- Package：Tape & Reel (TR)
- Type：Isolated Module
- Number of Outputs：2
- Voltage - Input (Min)：14.25V
- Voltage - Input (Max)：15.75V
- Voltage - Output 1：15V
- Voltage - Output 2：-15V
- Voltage - Output 3：-
- Voltage - Output 4：-
- Current - Output (Max)：34mA, 34mA
- Power (Watts)：1 W
- Voltage - Isolation：1.5 kV
- Applications：ITE (Commercial)
- Features：-
- Operating Temperature：-40°C ~ 105°C (With Derating)
- Efficiency：87%
- Mounting Type：Surface Mount
- Package / Case：10-SMD Module
- Size / Dimension：0.60" L x 0.31" W x 0.29" H (15.2mm x 8.0mm x 7.3mm)
- Supplier Device Package：-
- Control Features：-
- Approval Agency：-
- Standard Number：62368-1
- Grade：-
- Qualification：-
