1VR1

Overview

The TE Connectivity Corcom Filters 1VR1 is a single-phase EMC/EMI line filter designed for general-purpose applications. It features a two-stage configuration suitable for low impedance loads in noisy RFI environments. The component operates at 250VAC and 50/60Hz with a rated current of 1A. It utilizes quick connect terminals for termination and supports chassis mounting.

Feature Summary

• Two-stage filtering architecture
• Designed for low impedance loads
• Effective in noisy RFI environments

Applications

• General purpose electronic equipment
• Low impedance load protection
• RFI noise suppression

Procurement Notes

Verify the specific datasheet for the 1VR1 model to confirm exact terminal dimensions and mounting hole specifications. Ensure compatibility with the target chassis thickness and verify that the quick connect tab size matches the mating connector pins. Confirm regulatory certifications required for the final assembly.

Selection Notes

Select this component when a two-stage filter is required for low impedance applications. The 1VR1 is appropriate for environments with significant RFI noise. Compare against other Corcom series filters if higher current ratings or different mounting styles are needed. Verify voltage and frequency requirements match the system design.

Part Context

This part belongs to the TE Connectivity Corcom Filters family, which specializes in power line filters. The 1VR1 is a single-phase unit within this portfolio, focusing on EMI/RFI suppression. It complements other Corcom products by offering a specific solution for low impedance loads where standard filters may not perform optimally.

Replacement Considerations

Check for direct substitutes within the Corcom HQ or SRB series if availability is an issue. Ensure any replacement maintains the two-stage topology and 1A rating. Verify terminal type and mounting style compatibility before substitution.
