2-2443554-2

Overview

The TE Connectivity Corcom Filters model 2-2443554-2 is a high voltage DC EMI filter belonging to the EVX series. It features a two-stage filtering architecture designed for electric vehicle applications. The component has a voltage rating of 1000 VDC and a current rating of 1600 A. It utilizes busbar input and output connections with chassis mounting style. The operating temperature range spans from -40°C to +100°C.

Feature Summary

• Two-stage DC EMI filtering architecture
• High voltage and high current capacity design
• Busbar terminal configuration

Applications

• Electric vehicle charging systems
• High-power DC converter circuits

Procurement Notes

Verify the specific part number against official TE Connectivity documentation to confirm current availability status, as manufacturing lifecycles may change. Ensure that the 1600 A current rating and 1000 VDC voltage specifications match your system requirements before procurement. Check for any updated compliance certifications or environmental declarations required for your region.

Selection Notes

Select this component when designing high-power DC systems requiring robust EMI attenuation. The 1600 A rating supports heavy-duty industrial and automotive loads. Ensure the chassis mount form factor fits the enclosure constraints. Verify that the busbar termination method aligns with the existing power distribution infrastructure.

Part Context

This filter is part of the Corcom EVX series, which specializes in high-performance power line filters for demanding environments. The EVX series is engineered to handle significant electrical stresses while maintaining signal integrity. This specific model targets the growing market for electric mobility and renewable energy infrastructure.

Replacement Considerations

Consult official TE Connectivity substitution guides for verified alternatives. Generic cross-references may not match the specific 1600 A current handling or two-stage attenuation characteristics.
