2-6609075-9

Overview

The TE Connectivity Corcom Filters part number 2-6609075-9 is a compact RFI line filter designed for DC applications. It features a DC inlet connection and utilizes surface mount (SMD) tab termination for PCB integration. The component is rated for a current of 15 A and operates at voltages up to 125 VDC. This single-phase filter provides electromagnetic interference suppression for electronic equipment requiring direct current power entry with integrated filtering capabilities.

Feature Summary

• Integrates RFI/EMI filtering directly into the DC power entry module
• Utilizes surface mount tab connections for automated PCB assembly
• Designed as a compact solution for space-constrained electronic enclosures

Applications

• Industrial control systems requiring filtered DC power
• Medical equipment with strict EMI compliance needs
• Telecommunications infrastructure power supplies

Procurement Notes

Verify the specific voltage rating requirements against the datasheet, as this model is specified for DC applications up to 125V. Confirm that the surface mount tab termination style matches your PCB footprint design. Ensure the 15A current rating aligns with your system's maximum load. Check for any RoHS compliance status updates in the latest manufacturer documentation before finalizing procurement.

Selection Notes

Select this component when a combined DC power receptacle and EMI filter is required to save board space. It is suitable for designs where surface mount assembly is preferred over through-hole or wire lead connections. Consider the 15A capacity and 125VDC limit to ensure compatibility with the target power supply output. Verify mounting constraints and thermal management requirements for the SMD tab interface.

Part Context

This component belongs to the TE Connectivity Corcom Filters series, which specializes in power entry modules and line filters. The 2-6609075-9 variant specifically addresses DC input filtering needs, distinguishing it from AC-only models in the broader Corcom portfolio. It represents a specialized solution for integrating noise suppression directly at the power entry point of DC-powered devices.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material.
