2007088-3

$6.42

Description：CONN EDGE DUAL FML 24POS 0.100
Series：Standard Edge II
Mfr：TE Connectivity AMP Connectors
Package：Bulk

SKU:dd0535ab8e7b Category: Edgeboard Connectors Brand: TE Connectivity AMP Connectors

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

2007088-3 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists TE Connectivity AMP Connectors. Its product description is CONN EDGE DUAL FML 24POS 0.100. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 2007088-3

Description：CONN EDGE DUAL FML 24POS 0.100
Series：Standard Edge II
Mfr：TE Connectivity AMP Connectors
Package：Bulk
Card Type：Non Specified - Dual Edge
Gender：Female
Number of Positions/Bay/Row：-
Number of Positions：24 (16 + 8 Power)
Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
Number of Rows：2
Pitch：0.100" (2.54mm)
Read Out：Dual
Features：-
Mounting Type：Surface Mount
Termination：Solder
Contact Material：Copper
Contact Finish：Gold
Contact Finish Thickness：30.0µin (0.76µm)
Contact Type：-
Color：Black
Flange Feature：-
Operating Temperature：-55°C ~ 85°C

Edgeboard Connectors datasheet and documents for 2007088-3

2007088-3

Edgeboard Connectors Overview

The TE Connectivity AMP Connectors part number 2007088-3 is a Card Edge Power Connector designed for board-to-board applications. It features a total of 12 positions with a centerline pitch of 2.54 mm (0.1 in). The contact configuration includes 8 power positions, 16 signal positions, and 4 dual positions. The connector supports a current range from 5.2A to 46A per pitch and offers a resistance range of 0.7mΩ to 10mΩ. It has a maximum power rating of 3400W. The physical dimensions include a total length of 2.260 inches (57.40 mm) and a card slot dimension of 2.100 inches (53.40 mm).

Edgeboard Connectors Feature Summary

Designed for straddle-mount applications on co-planar printed circuit boards.
Integrates dedicated power and signal contacts within a single connector housing.
Supports high power ratings up to 3400W with low resistance characteristics.

Edgeboard Connectors Applications

Board-to-board interconnects requiring combined power and signal transmission.
Straddle-mount configurations on co-planar PCBs.
High-power density electronic assemblies.

Edgeboard Connectors Procurement Notes

Verify the specific pinout configuration and mechanical mounting requirements against the official datasheet before procurement. Ensure that the receiving PCB accommodates the specified card slot dimensions and total length. Confirm compatibility with the target current and voltage levels, as the component supports a wide operational range. Cross-reference the manufacturer's documentation for any recent product change notices or environmental compliance updates.

Edgeboard Connectors Selection Notes

Select this component when a combined power and signal solution is required for board-to-board connections. The 2.54 mm pitch provides standard spacing for power distribution while accommodating signal lines. Consider the 3400W power rating and low resistance values for high-current applications. Ensure the design utilizes the straddle-mount style suitable for co-planar board arrangements. Evaluate the 8 power and 16 signal position layout against system connectivity needs.

Edgeboard Connectors Part Context

This component belongs to the SEC-II Power Connector series by TE Connectivity AMP Connectors. It is specifically engineered for robust power delivery in compact board-to-board interfaces. The series is known for supporting high current densities and offering reliable electrical performance in demanding environments. It serves as a specialized solution for applications needing integrated power and signal routing without separate connectors.
