2011-3X06G00SB

Overview

The Oupiin 2011-3X06G00SB is a board-to-board connector header featuring 18 contacts arranged in three rows. It utilizes a 0.100-inch (2.54mm) pitch and employs through-hole solder terminals for secure PCB mounting. The component is designed as a male pin configuration, providing reliable signal transmission interfaces for electronic assemblies requiring standard spacing and robust mechanical connection.

Feature Summary

• Three-row male pin header configuration
• Standard 0.100 inch contact pitch
• Through-hole solder termination method

Applications

• General-purpose board-to-board interconnections
• Electronic assembly signal routing
• Industrial equipment internal wiring

Procurement Notes

Verify the specific row count and contact arrangement against the designator '3X' to ensure compatibility with mating female sockets. Confirm that the through-hole footprint matches the target PCB layout. Check material specifications for environmental compliance requirements if applicable to the end-use environment.

Selection Notes

Select this component when a multi-row male header with standard 2.54mm spacing is required. Ensure the mating interface supports three-row alignment. Consider current rating and plating thickness if high reliability or corrosive environments are anticipated during operation.

Part Context

This part belongs to the Oupiin 2011 series of headers. The series typically offers various contact counts and row configurations. This specific model provides a compact solution for connecting multiple signal lines between adjacent circuit boards using standard industrial pitch dimensions.

Replacement Considerations

Compatible replacements must match the 3-row, 18-contact geometry and 0.100-inch pitch. Verify that alternative manufacturers provide identical through-hole terminal styles and male gender specifications to maintain mechanical and electrical interchangeability.
