Product Detailed Parameters
- Description：PIN HEADER, SINGLE ROW, 40 PIN,
- Series：2015
- Mfr：Oupiin
- Package：Bulk
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.100" (2.54mm)
- Number of Positions：40
- Number of Rows：1
- Row Spacing - Mating：-
- Number of Positions Loaded：All
- Style：Board to Board
- Shrouding：Unshrouded
- Mounting Type：Surface Mount
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.244" (6.20mm)
- Contact Length - Post：-
- Overall Contact Length：-
- Insulation Height：0.098" (2.50mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：-
- Contact Finish - Post：Gold
- Contact Material：Copper Alloy
- Insulation Material：Plastic
- Features：-
- Operating Temperature：-40°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：-
- Current Rating (Amps)：2A
- Voltage Rating：-
Download product information
Overview
The Oupiin 2015-1X40G01DBB is a single-row male pin header connector designed for surface mount termination. It features 40 positions with a 2.54mm (0.100 inch) pitch. The component is constructed to provide robust interconnect behavior, suitable for applications requiring stability under vibration and field handling conditions.
Feature Summary
- Single row male pin configuration for direct board-to-board or cable connections
- Surface mount termination method for automated assembly integration
- Designed for stable performance in environments subject to mechanical vibration
Applications
- General electronic equipment interconnects
- Industrial control systems requiring vibration resistance
- Consumer electronics assemblies
Procurement Notes
Verify the specific suffix 'DBB' against the manufacturer's current datasheet to confirm exact housing color, terminal plating, and RoHS compliance status. Ensure the selected variant matches the required surface mount footprint and thermal profile specifications for the intended manufacturing process.
Selection Notes
Select this component when a single-row, 40-position interface with a standard 2.54mm pitch is required. Prioritize this part for designs needing surface mount compatibility and enhanced mechanical durability compared to through-hole alternatives. Confirm that the current rating and voltage ratings meet the system's electrical requirements.
Part Context
This part belongs to the Oupiin 2015 series of headers, which are characterized by single-row male pin configurations. The series offers various contact counts and termination styles, positioning these connectors as standard solutions for general-purpose PCB interconnections where reliable signal transmission is necessary.
Replacement Considerations
Public confirmed substitute part numbers are not available in the provided documentation. Cross-reference with other manufacturers offering 2.54mm pitch, 40-position, single-row SMD male headers if alternative sourcing is required.
