202/002

Description：OMNILOG 70600 680MHZ-6GHZ
Series：-
Mfr：Aaronia AG
Package：Bulk

SKU:aaa314169b15 Category: RF Antennas Brand: Aaronia AG

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：OMNILOG 70600 680MHZ-6GHZ
Series：-
Mfr：Aaronia AG
Package：Bulk
RF Family/Standard：-
Frequency Group：UHF (3GHz ~ 4GHz)
Frequency (Center/Band)：3.34GHz
Frequency Range：680MHz ~ 6GHz
Antenna Type：Blade, Tilt
Number of Bands：1
VSWR：3
Return Loss：-
Gain：3dBi
Features：-
Termination：SMA
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：-
Height (Max)：6.811" (173.00mm)
Applications：-
Power - Max：5 W

Download product information

202/002

Overview

The Aaronia AG 202/002 is an OmniLOG I-Bar multi-band antenna designed for wideband signal reception. It operates within a frequency range of 680 MHz to 6 GHz, covering multiple wireless standards including 2G (GSM/GPRS), 3G (UMTS), 4G (LTE), 5G, GPS, and dual-band WiFi. The component features an SMA male connector for interface compatibility. This omnidirectional antenna is engineered for applications requiring broad spectral coverage across cellular and satellite navigation bands.

Feature Summary

Supports multi-band reception across 2G, 3G, 4G, 5G, GPS, and WiFi frequencies
Utilizes I-Bar design for omnidirectional signal capture
Equipped with SMA male connector for direct integration

Applications

Real-time spectrum analysis monitoring
Wireless communication signal testing
GPS and satellite navigation system verification

Procurement Notes

Verify the specific datasheet version against the manufacturer's official documentation to confirm current specifications. Ensure the SMA male connector type matches the receiving equipment interface requirements. Cross-reference the part number 202/002 with authorized distributor lists to validate authenticity and avoid counterfeit components during procurement.

Selection Notes

Select this antenna when broad frequency coverage from 680 MHz to 6 GHz is required for a single unit. It is suitable for environments needing simultaneous monitoring of cellular, GPS, and WiFi signals. Consider the physical dimensions and mounting options relative to the installation space constraints before finalizing the selection.

Part Context

This model belongs to the OmniLOG series by Aaronia AG, which specializes in antennas for real-time spectrum analyzers. The 202/002 variant specifically targets the 680 MHz to 6 GHz band, distinguishing it from other models like the 202/003 that may cover different frequency ranges or have distinct performance characteristics within the same product family.
