2041-1X03G00SB

Overview

The Oupiin 2041-1X03G00SB is a rectangular board connector designed for secure PCB interconnections. It features three contacts arranged in a single row with female socket terminals. The component utilizes a 0.1-inch (2.54mm) pitch and employs straight solder termination for reliable mounting. Constructed with black insulator material, it provides stable electrical performance suitable for general electronic applications requiring durable board-to-board or board-to-wire connections.

Feature Summary

• Features a single row of female contact sockets for standardized mating interfaces
• Utilizes a 0.1-inch pitch to ensure consistent alignment and spacing
• Designed with straight solder terminals for direct printed circuit board mounting

Applications

• General electronic equipment board interconnections
• Industrial control system signal routing
• Consumer electronics internal wiring harnesses

Procurement Notes

Verify the specific datasheet version when sourcing this component to confirm insulation height and terminal plating specifications. Ensure that the procurement documentation explicitly references the full part number including the suffix to distinguish it from similar variants within the 2041 series. Cross-reference the manufacturer's official catalog to confirm current availability status and compliance certifications before finalizing orders.

Selection Notes

Select this connector when a low-profile, single-row female header is required for 2.54mm pitch applications. Consider the straight orientation for standard vertical mounting configurations. Evaluate the mechanical stability requirements against the single-row design constraints. Confirm that the operating environment aligns with the standard temperature ratings specified for this series of rectangular connectors.

Part Context

This component belongs to the Oupiin 2041 series of rectangular connectors, which are engineered for versatile board connection needs. The series offers various contact counts and orientations to support different assembly requirements. This specific model represents a compact solution for applications requiring minimal footprint while maintaining reliable signal transmission through standardized pin spacing.

Replacement Considerations

Compatible substitutes include other manufacturers' 3-pin, 2.54mm pitch, single-row female headers with matching dimensions. Verify that alternative parts maintain identical contact configuration, solder termination style, and insulator color coding to ensure seamless integration without mechanical modification.
