2042-1X04G00RB

Overview

The Oupiin 2042-1X04G00RB is a single-row female board connector featuring four contacts with a 0.1-inch (2.54mm) pitch. It utilizes right-angle through-hole mounting for secure PCB attachment. The contacts are gold-plated to ensure reliable signal transmission and corrosion resistance. Designed as a socket receptacle, it supports multipal mating parts for flexible system integration.

Feature Summary

• Single-row female socket configuration for standard header mating
• Right-angle through-hole termination for vertical PCB integration
• Gold contact plating for enhanced conductivity and durability

Applications

• General electronic circuit interconnections
• Consumer electronics assembly
• Industrial control panel wiring

Procurement Notes

Verify RoHS compliance status and lead times directly with authorized distributors. Confirm that the specific suffix matches the required pin count and orientation. Ensure storage conditions maintain contact integrity prior to assembly.

Selection Notes

Select this component when a low-profile, right-angle female connector is required for 2.54mm pitch applications. Consider the mechanical locking features and current carrying capacity relative to the target circuit requirements before finalizing the design.

Part Context

This part belongs to the Oupiin 2042 series of board connectors. The series offers various contact counts and orientations. This specific model provides a compact solution for space-constrained designs requiring robust electrical connections.

Replacement Considerations

Check for compatible headers from other manufacturers with identical 2.54mm pitch and right-angle form factor. Verify mechanical dimensions and terminal compatibility before substitution.
