Product Detailed Parameters
- Description：PCB SOCKET, DOUBLE ROW, 14 PIN,
- Series：2042
- Mfr：Oupiin
- Package：Tray
- Connector Type：Socket
- Contact Type：Female Socket
- Style：Board to Board
- Number of Positions：14
- Number of Positions Loaded：All
- Pitch - Mating：0.100" (2.54mm)
- Number of Rows：2
- Row Spacing - Mating：0.100" (2.54mm)
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：Flash
- Insulation Color：-
- Insulation Height：0.224" (5.70mm)
- Contact Length - Post：0.126" (3.20mm)
- Operating Temperature：-55°C ~ 105°C
- Material Flammability Rating：UL94 V-0
- Contact Finish - Post：Gold
- Mated Stacking Heights：-
- Ingress Protection：-
- Features：-
- Current Rating (Amps)：2A
- Voltage Rating：-
Download product information
Overview
The Oupiin 2042-2X07G00SA is a board-to-board socket connector featuring 14 positions arranged in two rows. It utilizes a 0.100 inch (2.54mm) contact pitch and employs a straight through-hole mounting style for PCB integration. The component incorporates gold-plated female contacts to ensure reliable signal transmission and corrosion resistance. Designed as a low-profile receptacle, it provides secure locking mechanisms to maintain stable connections during operation.
Feature Summary
- Features gold-plated female contacts for enhanced conductivity
- Utilizes a straight through-hole mounting configuration
- Incorporates a locking mechanism for secure retention
Applications
- General electronic circuit interconnections
- Board-to-board signal routing
- Low-frequency data transmission systems
Procurement Notes
Verify the specific part number suffix against official manufacturer documentation to confirm exact pin count and plating specifications. Ensure compatibility with mating header connectors regarding pitch and row configuration. Confirm that the through-hole termination method aligns with the target printed circuit board assembly processes and mechanical constraints.
Selection Notes
Select this component when a double-row socket with a standard 2.54mm pitch is required for low-frequency applications. Consider the straight orientation and through-hole termination for rigid board-to-board connections. Evaluate the need for gold plating on female contacts to minimize contact resistance and improve durability in standard operating environments.
Part Context
This connector belongs to the Oupiin 204 series of board connectors. The series offers various position counts and row configurations to suit different density requirements. As a standard rectangular socket, it serves as a fundamental interface component for establishing electrical pathways between separate circuit boards in consumer and industrial electronics assemblies.
Replacement Considerations
Compatible substitutes must match the 2.54mm pitch, 14-position double-row layout, and straight through-hole form factor. Verify that alternative sockets provide equivalent locking features and contact material specifications to ensure mechanical and electrical interchangeability without redesigning the host PCB.
