2043-2X12G00DNT-P

Description：PCB SOCKET, DOUBLE ROW, 24 PIN,
Series：2043
Mfr：Oupiin
Package：Tape & Reel (TR)

SKU:5172f3578af5 Category: Headers, Receptacles, Female Sockets Brand: Oupiin

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：PCB SOCKET, DOUBLE ROW, 24 PIN,
Series：2043
Mfr：Oupiin
Package：Tape & Reel (TR)
Connector Type：Socket
Contact Type：Female Socket
Style：Board to Board
Number of Positions：24
Number of Positions Loaded：All
Pitch - Mating：0.100" (2.54mm)
Number of Rows：2
Row Spacing - Mating：0.100" (2.54mm)
Mounting Type：Surface Mount
Termination：Solder
Fastening Type：Push-Pull
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：Flash
Insulation Color：-
Insulation Height：0.280" (7.10mm)
Contact Length - Post：-
Operating Temperature：-55°C ~ 105°C
Material Flammability Rating：UL94 V-0
Contact Finish - Post：Gold
Mated Stacking Heights：-
Ingress Protection：-
Features：Board Guide, Pick and Place
Current Rating (Amps)：2A
Voltage Rating：-

Download product information

2043-2X12G00DNT-P

Overview

The Oupiin 2043-2X12G00DNT-P is a PCB socket featuring a double-row configuration with 24 pins. It utilizes a 2.54mm pitch for mating and offers a row spacing of 2.54mm. The component operates within a temperature range of -55°C to +105°C. Contact plating is gold, while the contact material consists of copper alloy. The unit is RoHS compliant.

Feature Summary

Double-row PCB socket design
Gold-plated copper alloy contacts
RoHS compliant construction

Applications

General electronic circuit interconnections
PCB-to-PCB signal routing
Prototype development boards

Procurement Notes

Verify the specific pin count and row configuration against the target PCB footprint before integration. Confirm that the operating temperature range of -55°C to +105°C aligns with the environmental requirements of the final assembly. Ensure compatibility with standard 2.54mm header counterparts to guarantee reliable mechanical mating and electrical continuity.

Selection Notes

Select this component when a double-row socket interface with 24 positions is required. The 2.54mm pitch suits standard through-hole mounting processes. Consider the gold plating for corrosion resistance in demanding environments. Verify that the copper alloy contact material meets the current carrying needs of the application.

Part Context

This part belongs to the Oupiin connector portfolio, specifically designed as a PCB socket. It serves as an interface solution for electronic assemblies requiring removable connections. The double-row layout allows for higher density pin counts within a standard pitch format compared to single-row alternatives.
