2043-2X16G00SA

Overview

The Oupiin 2043-2X16G00SA is a 32-position female socket connector designed for through-hole PCB mounting. It features a 0.100-inch (2.54mm) contact pitch and square hole contacts. The mating surface utilizes gold plating to ensure reliable conductivity. The component operates within a temperature range of -55°C to +105°C and employs a push-pull fastening mechanism for secure connection.

Feature Summary

• Square hole contact design for precise pin alignment
• Gold-plated mating surfaces for enhanced conductivity
• Push-pull fastening type for secure engagement

Applications

• General electronic circuit interconnections
• Industrial control system modules
• Consumer electronics assemblies

Procurement Notes

Verify the specific suffix codes against official Oupiin documentation to confirm exact contact configuration and material specifications. Ensure compatibility with mating header dimensions before integration. Cross-reference operating temperature ratings with environmental requirements. Confirm through-hole footprint alignment with PCB layout constraints.

Selection Notes

Select this component when a 32-position female receptacle with 2.54mm pitch is required. The square hole design aids in accurate pin insertion. Gold plating supports applications needing stable electrical performance. Verify that the push-pull retention method meets mechanical stability needs for the target assembly.

Part Context

This part belongs to the Oupiin 2043 series of headers and wire housings. The series offers various position counts and configurations. The 2X16 designation indicates a dual-row arrangement totaling 32 positions. This series is engineered for standard through-hole mounting techniques on printed circuit boards.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Verify mechanical fit and electrical parameters if considering alternative manufacturers. Consult Oupiin technical support for direct equivalents.
