2044-2X04G00RB

Overview

The Oupiin 2044-2X04G00RB is a rectangular board connector featuring 8 contacts arranged in a double-row configuration. It utilizes a 0.1 inch (2.54mm) pitch and is designed for right-angle mounting on printed circuit boards. The component functions as a female socket with through-hole solder terminals, ensuring secure electrical connections for signal transmission.

Feature Summary

• Right-angle PCB mounting orientation
• Double-row female socket design
• Through-hole solder termination

Applications

• General electronic equipment interconnection
• Industrial control systems
• Consumer electronics assemblies

Procurement Notes

Verify the specific suffix 'RB' confirms the right-angle orientation and through-hole termination style required for your PCB layout. Confirm that the 8-contact count matches the target circuit density. Ensure mating headers are selected to match the 0.1 inch pitch specification for proper engagement.

Selection Notes

Select this component when a low-profile, right-angle connection is necessary for space-constrained designs. The double-row format allows for higher contact density within a limited footprint compared to single-row alternatives. Verify compatibility with standard 0.1 inch pitch mating hardware.

Part Context

This part belongs to the Oupiin series of rectangular board connectors, specifically designed for general-purpose interconnect applications. It represents a standard solution for connecting peripheral modules or daughterboards to main system boards using reliable through-hole technology.

Replacement Considerations

Direct substitutes must maintain the 0.1 inch pitch, 8-pin count, double-row female configuration, and right-angle through-hole mounting style. Cross-reference dimensions to ensure mechanical fit within the existing enclosure constraints.
