Product Detailed Parameters
- Description：PCB Socket 2.54mmX2.54mm Elevate
- Series：2047
- Mfr：Oupiin
- Package：Tube
- Connector Type：Receptacle
- Contact Type：Forked
- Style：Board to Board
- Number of Positions：30
- Number of Positions Loaded：All
- Pitch - Mating：0.100" (2.54mm)
- Number of Rows：-
- Row Spacing - Mating：0.100" (2.54mm)
- Mounting Type：Through Hole
- Termination：Press-Fit, Solder
- Fastening Type：Push-Pull
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：-
- Insulation Color：Black
- Insulation Height：0.435" (11.05mm)
- Contact Length - Post：0.126" (3.20mm)
- Operating Temperature：-55°C ~ 105°C
- Material Flammability Rating：UL94 V-0
- Contact Finish - Post：Gold
- Mated Stacking Heights：-
- Ingress Protection：-
- Features：-
- Current Rating (Amps)：2A
- Voltage Rating：-
Download product information
Overview
The Oupiin 2047-2X15G30SP1U is a rectangular connector receptacle designed for through-hole PCB mounting. It features a 2x15 pin configuration, providing 30 positions for signal or power transmission. The contact spacing is standardized at 0.100 inches (2.54 mm), ensuring compatibility with common board layouts. The contacts are finished with gold plating to ensure reliable conductivity and corrosion resistance over repeated mating cycles. The housing material is rated UL94 V-0 for flammability safety.
Feature Summary
- Gold-plated contacts for enhanced conductivity
- Through-hole mounting for secure PCB attachment
- UL94 V-0 rated insulation material
Applications
- General electronic equipment interconnects
- Industrial control systems
- Consumer electronics assemblies
Procurement Notes
Verify the specific suffix 'SP1U' against the manufacturer's latest datasheet to confirm exact plating thickness and housing color variations. Ensure the ordering part number matches the required 30-position count and 2.54mm pitch specifications. Confirm that the through-hole footprint aligns with your PCB design constraints before finalizing procurement.
Selection Notes
Select this component when a 30-position female header is required for vertical PCB mounting. The 2.54mm pitch allows for standard breadboard or prototyping compatibility. Consider the gold finish if high cycle life or low contact resistance is critical. Verify that the operating temperature range meets the application requirements.
Part Context
This part belongs to the Oupiin 2047 series of rectangular connectors. The series offers various pin counts and configurations to suit different density requirements. The 2047 series is characterized by its robust mechanical design and consistent electrical performance across multiple industrial and commercial applications.
Replacement Considerations
Direct substitutes must match the 2x15 position count, 2.54mm pitch, and through-hole mounting style. Generic equivalents from other manufacturers may require verification of housing dimensions and terminal locking mechanisms to ensure physical compatibility.
