2048-1X03G00BU

Overview

The Oupiin 2048-1X03G00BU is a single-row board connector featuring three contacts with a 0.100-inch (2.54mm) pitch. Designed as a through-hole receptacle, it utilizes gold-plated terminals for reliable signal transmission. The component is classified as a female socket header intended for PCB mounting.

Feature Summary

• Single-row configuration for compact circuit board integration
• Gold-plated contact surfaces to ensure stable electrical conductivity
• Through-hole termination method for secure mechanical attachment

Applications

• General electronic circuit interconnections
• PCB-to-PCB signal routing
• Low-density board-to-wire harness connections

Procurement Notes

Verify the specific suffix codes against official manufacturer documentation to confirm terminal plating and housing material specifications. Ensure the selected variant matches the required current rating and voltage class for the target application environment before finalizing procurement orders.

Selection Notes

Select this component when a low-pin-count, single-row interface is required. The 2.54mm pitch is standard for general-purpose electronics. Confirm that the through-hole mounting style aligns with the PCB design constraints and that the single-row layout fits within the available board area.

Part Context

This part belongs to the Oupiin 2048 series of rectangular connectors. The series offers various pin counts and row configurations to support diverse connectivity needs in computing and industrial equipment. The 2048-1X03G00BU represents a minimal contact option within this standardized product line.

Replacement Considerations

Cross-reference with other manufacturers offering 3-position, 2.54mm pitch single-row headers. Verify that physical dimensions, pin spacing, and termination type are identical to ensure mechanical compatibility without redesigning the PCB footprint.
