2049-2X05G00U

$0.70

Description：PCB SOCKET, DOUBLE ROW, 10 PINS,
Series：2049
Mfr：Oupiin
Package：Tube

SKU:67ba7e4c6344 Category: Headers, Receptacles, Female Sockets Brand: Oupiin

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：PCB SOCKET, DOUBLE ROW, 10 PINS,
Series：2049
Mfr：Oupiin
Package：Tube
Connector Type：Socket
Contact Type：Female Socket
Style：Board to Board
Number of Positions：10
Number of Positions Loaded：All
Pitch - Mating：0.100" (2.54mm)
Number of Rows：2
Row Spacing - Mating：0.100" (2.54mm)
Mounting Type：Through Hole, Right Angle
Termination：Solder
Fastening Type：Push-Pull
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：Flash
Insulation Color：-
Insulation Height：0.235" (5.97mm)
Contact Length - Post：0.126" (3.20mm)
Operating Temperature：-55°C ~ 105°C
Material Flammability Rating：UL94 V-0
Contact Finish - Post：Gold
Mated Stacking Heights：-
Ingress Protection：-
Features：-
Current Rating (Amps)：2A
Voltage Rating：-

Download product information

2049-2X05G00U

Overview

The Oupiin 2049-2X05G00U is a board-to-board connector featuring two rows of female sockets with a 0.050-inch (1.27mm) pitch. It utilizes a right-angle mounting configuration for surface-mount termination, designed to facilitate vertical interconnection between PCBs. The component incorporates locking mechanisms to ensure secure mating stability during operation.
