20AYO1

Overview

The TE Connectivity Corcom Filters 20AYO1 is a three-phase (Wye) EMC/EMI line filter designed to reduce electrical noise and protect sensitive equipment. It operates at AC voltages up to 440VAC with a current rating of 3A. The unit supports frequencies of 50Hz and 60Hz. It features spade terminals for connection and utilizes flange mounting for installation.

Feature Summary

• Provides EMI/RFI filtering solutions for three-phase systems
• Compact design suitable for low current applications
• Constructed for Wye configuration operation

Applications

• Protection of sensitive electronic equipment from electrical noise
• Three-phase power line filtering in industrial settings
• EMC compliance in commercial machinery

Procurement Notes

Verify the specific voltage and current requirements against the 440VAC and 3A ratings before procurement. Confirm that the spade terminal style matches the existing wiring harness. Ensure the flange mounting dimensions are compatible with the enclosure panel. Check for RoHS compliance status if required by project specifications.

Selection Notes

Select this component when three-phase Wye filtering is required for low-current circuits. Compare against other Corcom series filters for size constraints. Verify terminal type compatibility with available connectors. Consider operating temperature ranges if deployed in extreme environments.

Part Context

This part belongs to the Corcom AYO series, which specializes in compact, low-current three-phase RFI filters. The series is recognized globally for providing effective EMI/RFI filtering solutions in various industrial and commercial applications.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
