20EP6

Overview

The TE Connectivity Corcom Filters 20EP6 is a single-phase power line filter rated for 20 A at 250 VAC and 50/60 Hz. It belongs to the EP series and features chassis mounting with flange installation. The component provides EMI/RFI suppression for general applications, utilizing quick-connect termination styles.

Feature Summary

• Provides single-phase EMI/RFI noise attenuation
• Supports chassis mounting via flange design
• Utilizes quick-connect termination style

Applications

• Industrial automation equipment
• Medical devices
• Telecommunications infrastructure
• Renewable energy systems
• Consumer electronics

Procurement Notes

Verify the specific datasheet version for the 20EP6 model to confirm exact dimensional tolerances and certification marks (UL, CSA, VDE). Ensure the application environment temperature aligns with the specified operating range. Confirm that the quick-connect terminal dimensions match the mating harness requirements before procurement.

Selection Notes

Select the 20EP6 when a 20 A current rating and 250 VAC voltage are required for single-phase power entry. Consider this model for chassis-mounted installations where flange attachment is preferred over panel cutouts. Evaluate the need for EMI suppression in conjunction with power entry functions for compact system designs.

Part Context

This component is part of the TE Connectivity Corcom Filters portfolio, which specializes in electromagnetic compatibility solutions. The EP series specifically addresses high-current power line filtering needs. These filters are designed to meet international safety standards, ensuring reliable operation in demanding electrical environments across various industrial and commercial sectors.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
