20VS6

Overview

The TE Connectivity Corcom Filters 20VS6 is a single-phase EMC/EMI line filter designed for chassis mounting. It supports a rated current of 20 A and operates at AC voltages of 120 VAC or 250 VAC with a frequency of 50/60 Hz. The unit features a two-stage filtering configuration to enhance noise suppression. Termination is achieved via threaded posts, specifically 8-32 threads, ensuring secure electrical connections.

Feature Summary

• Two-stage filtering architecture for effective EMI/RFI suppression
• Chassis mount design with threaded post termination
• Dual voltage rating capability for 120VAC and 250VAC systems

Applications

• Industrial equipment power input stages
• Medical device power supplies
• General purpose electronic enclosures requiring EMI protection

Procurement Notes

Verify the specific voltage requirement (120VAC vs 250VAC) and confirm the threaded post specification (8-32) matches the panel assembly. Ensure the chassis mounting method aligns with the mechanical constraints of the target enclosure. Cross-reference the manufacturer datasheet for any recent product change notices or obsolescence alerts before finalizing procurement plans.

Selection Notes

Select this component when high-current single-phase filtering is required in a compact chassis-mount form factor. The two-stage design offers superior attenuation compared to single-stage alternatives. Consider the thermal environment and ensure the operating temperature range accommodates the application's ambient conditions. Verify that the 20A current rating exceeds the maximum load current with appropriate safety margins.

Part Context

This part belongs to the TE Connectivity Corcom Filters series, which specializes in power line filters for industrial and commercial applications. The 20VS6 model represents a robust solution for managing electromagnetic interference in power distribution systems where space is limited but performance requirements are stringent.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Consult the manufacturer's selector guide for equivalent models within the same series or compatible alternative brands if direct substitution is necessary.
