20VT6

Overview

The TE Connectivity Corcom Filters 20VT6 is a single-phase EMC/EMI line filter designed for chassis mounting. It supports a rated current of 20 A at 250 VAC and operates at 50/60 Hz frequencies. The unit features a single-stage filtering configuration with termination via threaded posts (8-32). This component is intended for general-purpose applications requiring power line noise suppression.

Feature Summary

• Provides single-stage EMI/RFI filtering for AC power lines
• Features threaded post termination for secure chassis installation
• Designed for general-purpose industrial and commercial equipment

Applications

• Industrial machinery power supplies
• Commercial electronic equipment
• General-purpose AC power distribution systems

Procurement Notes

Verify the specific datasheet version before procurement, as TE Connectivity may update specifications or pin configurations over time. Confirm that the 8-32 threaded post termination matches your chassis mounting hardware requirements. Ensure the 20A current rating and 250VAC voltage rating are sufficient for your application's peak load conditions to prevent component failure.

Selection Notes

Select this model when a single-stage filter solution is required for 20A circuits. The threaded post termination necessitates compatible mounting hardware on the chassis. Compare against multi-stage alternatives if higher attenuation is needed. Verify that the physical dimensions of the threaded post assembly fit within the available panel space.

Part Context

This component belongs to the TE Connectivity Corcom Filters series, which specializes in power line filters for electromagnetic interference suppression. The 20VT6 represents a high-current variant within their single-phase lineup, utilizing robust threaded connections rather than quick-connect terminals found in lower-current models.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
