2111-1X08G00RB

Overview

The Oupiin 2111-1X08G00RB is a single-row male pin header featuring eight contacts with a 2.0mm (0.079 inch) pitch. It utilizes a right-angle configuration for board mounting via solder terminals. The connector employs brass contact material with gold plating to ensure reliable signal transmission. Designed for through-hole assembly, it supports a voltage rating of 125V. The component measures 0.118 inches in mating contact length and 0.146 inches in total contact length, providing a compact solution for interconnecting circuit boards.

Feature Summary

• Single-row male pin configuration for straightforward board-to-board connectivity
• Right-angle orientation facilitates space-efficient PCB layout arrangements
• Gold-plated brass contacts provide corrosion resistance and stable electrical performance
• Through-hole solder terminal design ensures secure mechanical attachment

Applications

• Interconnecting daughterboards to main logic boards in consumer electronics
• Signal routing within industrial control systems requiring right-angle headers
• Connection points in telecommunications equipment housing
• Internal wiring interfaces in automated manufacturing machinery

Procurement Notes

Verify the specific suffix designation against the manufacturer's current catalog to confirm exact physical dimensions and insulation height variants. Ensure compatibility with mating socket connectors regarding pitch tolerance and contact retention force. Confirm that the selected variant meets the required operating temperature range for the intended application environment before finalizing procurement orders.

Selection Notes

Select this component when a single-row, right-angle interface is required with an 8-position count. The 2.0mm pitch suits applications where spacing constraints allow for wider traces compared to finer pitches. Consider the through-hole mounting method if surface-mount alternatives are not feasible due to thermal or mechanical stress requirements during assembly processes.

Part Context

This part belongs to the Oupiin 2111 series, which encompasses various pin header configurations including straight and right-angle options across different row counts and pitches. The series is designed for general-purpose electronic interconnections, offering standardized dimensions to facilitate integration into diverse electronic assemblies ranging from computer peripherals to industrial instrumentation.

Replacement Considerations

Equivalent parts include the 2111-1X200RB, which shares similar male pin characteristics but may differ in specific dimensional tolerances or contact material specifications. Verify cross-compatibility by comparing pitch, row count, and mounting style before substituting.
