Product Detailed Parameters
- Description：PIN HEADER, SINGLE ROW, 5 PIN, S
- Series：2112
- Mfr：Oupiin
- Package：Bulk
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.079" (2.00mm)
- Number of Positions：5
- Number of Rows：1
- Row Spacing - Mating：-
- Number of Positions Loaded：All
- Style：Board to Board
- Shrouding：Unshrouded
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.154" (3.90mm)
- Contact Length - Post：0.110" (2.80mm)
- Overall Contact Length：0.343" (8.70mm)
- Insulation Height：0.079" (2.00mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：Flash
- Contact Finish - Post：Gold
- Contact Material：Brass
- Insulation Material：Polybutylene Terephthalate (PBT)
- Features：-
- Operating Temperature：-40°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：1A
- Voltage Rating：-
Download product information
Overview
The Oupiin 2112-1X05G00SB is a single-row board connector designed for through-hole mounting. It features five male pin contacts with a square shape and a pitch of 0.079 inches (2.00mm). The component utilizes a solder termination method and incorporates a push-pull fastening mechanism to ensure secure attachment. This header is engineered for reliable electrical connections in compact electronic assemblies.
Feature Summary
- Single row configuration with five male pins
- Square contact shape for precise alignment
- Through-hole solder termination for robust mechanical stability
- Push-pull fastening type for secure mating
Applications
- General purpose PCB interconnections
- Compact electronic device assembly
- Signal routing between circuit boards
Procurement Notes
Verify the specific pin count and pitch against design requirements before procurement. Confirm that the push-pull fastening mechanism aligns with the mating interface constraints. Ensure the through-hole termination method matches the target PCB layout specifications to guarantee proper installation and electrical continuity.
Selection Notes
Select this component when a single-row, five-position male header is required. The 0.079-inch pitch suits applications needing standard spacing. The push-pull feature offers enhanced retention compared to standard headers. Consider the square pin shape for compatibility with corresponding socket designs.
Part Context
This part belongs to the Oupiin 2112 series of rectangular connectors. The series includes various configurations with different row counts and pin numbers. The 2112-1X05G00SB represents the single-row variant, providing a specialized solution for low-density interconnect needs within the broader product line.
Replacement Considerations
Compatible substitutes include other single-row headers with identical 0.079-inch pitch and five-pin count. Ensure replacement parts maintain the same male pin configuration and push-pull fastening style to preserve mechanical integrity and connection reliability.
