Product Detailed Parameters
- Description：PIN HEADER, SINGLE ROW, 6 PIN, S
- Series：2115
- Mfr：Oupiin
- Package：Bulk
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.079" (2.00mm)
- Number of Positions：6
- Number of Rows：1
- Row Spacing - Mating：-
- Number of Positions Loaded：All
- Style：Board to Board
- Shrouding：Unshrouded
- Mounting Type：Surface Mount
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.157" (4.00mm)
- Contact Length - Post：-
- Overall Contact Length：-
- Insulation Height：0.059" (1.50mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：Flash
- Contact Finish - Post：Gold
- Contact Material：Brass
- Insulation Material：Polyamide (PA6T), Nylon 6T
- Features：-
- Operating Temperature：-40°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：2A
- Voltage Rating：-
Download product information
Overview
The Oupiin 2115-1X06G00DA-4U is a surface mount pin header featuring six positions in a single row. It utilizes a 2.00mm (0.079 inch) pitch for contact spacing and provides a mating contact length of 4.00mm (0.157 inch). The connector supports a current rating of 2A and employs polyamide (PA6T) or nylon insulation material. Designed for solder termination, this component ensures reliable board-to-board connections with stable electrical performance.
Feature Summary
- Single row surface mount configuration for compact circuit board integration
- Polyamide (PA6T) or nylon insulation housing for thermal stability
- Solder termination method ensuring secure mechanical attachment
Applications
- General electronic equipment interconnections
- Industrial control system modules
- Consumer electronics internal wiring
Procurement Notes
Verify the specific insulation material designation, as datasheets may list either PA6T or Nylon variants for this part number. Confirm that the required current rating of 2A aligns with the application's power distribution needs. Ensure the surface mount footprint matches the PCB design specifications to guarantee proper solder joint integrity during assembly.
Selection Notes
Select this component when a low-profile, single-row header is required for surface mounting. The 2.00mm pitch offers a balance between density and ease of handling. Consider the 2A current rating and 4.00mm contact length to ensure compatibility with mating pins and adequate signal transmission capabilities for the intended circuit load.
Part Context
This connector belongs to the Oupiin 2115 series, which specializes in 2.00mm pitch pin headers. The series includes various configurations such as dual-row and right-angle options. The 2115 series is designed for applications requiring robust surface mount connectivity with standardized spacing dimensions suitable for modern electronic assemblies.
Replacement Considerations
Direct substitutes within the same series include other 2115 model variants with matching 2.00mm pitch and single-row layout. Verify that any alternative part maintains the same 6-position count and surface mount termination style to ensure mechanical and electrical compatibility.
