2122100041

$1.24

Description：CP-3.3 W/B HDR ASSY DR ST DIP BL
Series：CP-3.3 212210
Mfr：Molex
Package：Tray

SKU:a2364a861c2d Category: Headers, Male Pins Brand: Molex

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

2122100041 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Molex. Its product description is CP-3.3 W/B HDR ASSY DR ST DIP BL. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for 2122100041

Description：CP-3.3 W/B HDR ASSY DR ST DIP BL
Series：CP-3.3 212210
Mfr：Molex
Package：Tray
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.130" (3.30mm)
Number of Positions：4
Number of Rows：2
Row Spacing - Mating：0.163" (4.14mm)
Number of Positions Loaded：All
Style：Board to Cable/Wire
Shrouding：Shrouded - 4 Wall
Mounting Type：Through Hole
Termination：Kinked Pin, Solder
Fastening Type：Latch Holder
Contact Length - Mating：-
Contact Length - Post：0.132" (3.35mm)
Overall Contact Length：-
Insulation Height：0.549" (13.94mm)
Contact Shape：Square
Contact Finish - Mating：Tin
Contact Finish Thickness - Mating：39.4µin (1.00µm)
Contact Finish - Post：Tin
Contact Material：Copper Alloy
Insulation Material：Polyamide (PA), Nylon, Glass Filled
Features：Board Guide, Glow Wire Compliant
Operating Temperature：-40°C ~ 105°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：Varies by Wire Gauge
Voltage Rating：500VAC/DC

Headers, Male Pins datasheet and documents for 2122100041

2122100041

Headers, Male Pins Overview

Molex part number 212210-0041 is a compact wire-to-board connector header designed for high performance and durability in harsh conditions. It features a 1mm pitch, two rows of contacts, and a total of four positions. The connector utilizes through-hole straight mounting with a 3.3mm (0.130 inch) mating height. Constructed with black housing, it supports up to 864W power delivery to peripheral devices as defined within relevant standards.

Headers, Male Pins Feature Summary

Compact 1mm pitch design for high-density applications
Supports up to 864W power delivery capabilities
Durable construction suitable for harsh operating environments

Headers, Male Pins Applications

High-performance peripheral device connections
Harsh condition electronic assemblies
Wire-to-board power distribution systems

Headers, Male Pins Procurement Notes

Verify the exact part number format, noting that 212210-0041 and 2122100041 refer to the same component. Confirm RoHS compliance status and specific packaging quantities with authorized distributors. Ensure the supplier provides official Molex documentation to validate authenticity and technical specifications before purchase.

Headers, Male Pins Selection Notes

Select this connector when space constraints require a 1mm pitch header. Choose this model for applications demanding robust performance in challenging environments. Ensure the design accommodates the 3.3mm height and through-hole mounting requirements. Verify power delivery needs align with the 864W capability definition.

Headers, Male Pins Part Context

This component belongs to Molex's compact wire-to-board connector family. It is engineered for reliability in demanding industrial and consumer electronics. The 212210 series offers a balance of density and power handling. It serves as a critical interconnection solution for modern peripheral interfaces.
