2131D2*15GSE

Headers, Male Pins Overview

The Marutsuelec 2131D2*15GSE is a vertical header connector designed for through-hole mounting. It features a 2.54 mm (0.100 inch) contact pitch and provides 15 positions in a single row configuration. The component utilizes male pin contacts to establish secure electrical connections between circuit boards or cable assemblies. This specific part number denotes the 15-position variant within the 2131D2 series, ensuring compatibility with standard PCB layouts requiring this density.

Headers, Male Pins Feature Summary

• Vertical orientation for board-to-board or cable interconnects
• Through-hole mounting style for robust mechanical stability
• Standard 2.54 mm pitch for broad industry compatibility

Headers, Male Pins Applications

• General electronic equipment interconnections
• Industrial control panel wiring
• Consumer appliance internal harnesses

Headers, Male Pins Procurement Notes

Verify the exact position count matches the design requirement, as the series includes variants from 2 to 15 positions. Confirm that the vertical height and housing material specifications align with the assembly constraints. Ensure the supplier source is authorized to guarantee genuine Marutsuelec components without counterfeit risks.

Headers, Male Pins Selection Notes

Select this connector when a 15-channel vertical interface is required on a printed circuit board. The 2.54 mm pitch is suitable for standard signal and low-power applications. Consider the physical clearance above the PCB surface to ensure no interference with adjacent components or enclosure structures during assembly.

Headers, Male Pins Part Context

This component belongs to the Marutsuelec 2131D2 series of vertical headers. The series offers multiple position options, allowing designers to choose the appropriate density for their specific routing needs while maintaining consistent mechanical and electrical characteristics across the product line.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other manufacturers' 15-position, 2.54 mm pitch vertical headers with through-hole pins. Verify that the substitute maintains identical pin spacing, current rating, and insulation voltage specifications to ensure functional equivalence.
