2131D2*25GSE

Headers, Male Pins Overview

The Marutsuelec 2131D2*25GSE is a vertical male pin header connector designed for through-hole mounting. It features 25 positions with a 0.100-inch (2.54mm) pitch. The unit utilizes square contact shapes and PBT & 30% glass fiber insulation rated UL 94V-0. Key dimensions include an insulation height of 0.100 inches, a post contact length of 0.118 inches, and an overall contact length of 0.457 inches.

Headers, Male Pins Feature Summary

• Vertical orientation for board-to-board or cable connections
• Square pin contact shape for secure mating
• Flame-retardant insulator material construction

Headers, Male Pins Applications

• General electronic circuit interconnections
• Industrial control panel wiring
• Consumer electronics assembly

Headers, Male Pins Procurement Notes

Verify the specific position count matches the required design layout before ordering. Confirm that the through-hole footprint on the target PCB aligns with the 2.54mm pitch specification. Ensure the vertical profile fits within the mechanical enclosure constraints. Check for any specific surface finish requirements if solderability is critical to the application environment.

Headers, Male Pins Selection Notes

Select this component when a standard 2.54mm pitch vertical header is required. The 25-position configuration suits applications needing moderate I/O density. Consider the square pin geometry for robust mechanical retention during mating cycles. Verify that the operating temperature range accommodates the intended environmental conditions.

Headers, Male Pins Part Context

This part belongs to the 2131 series of male pin headers from Marutsuelec. The series offers various position counts while maintaining consistent 2.54mm spacing. These connectors are commonly used in industrial and commercial equipment where reliable signal transmission is necessary. The product line emphasizes durability and standardized dimensions for easy integration.

Headers, Male Pins Replacement Considerations

Compatible substitutes must maintain the 2.54mm pitch, vertical orientation, and 25-position count. Insulator material properties should match or exceed UL 94V-0 ratings. Contact shape compatibility is essential for mating with existing sockets.
