2134586

Overview

The SICK part number 2134586 corresponds to the RFU610-10605, a short-range RFID read/write device with an integrated antenna. It operates in the UHF band (860MHz–960MHz) at carrier frequencies of 920.625MHz and 924.375MHz. The unit delivers an output power of 25mW (ERP, 14dBm) and supports EPCglobal UHF Class 1 Generation 2, ISO/IEC 18000-6 C, and Rain modulation PR-ASK standards. Connectivity is provided via PoE. The integrated antenna features a 110° aperture angle, circular polarization with a typical axial ratio of 3dB, and a front-to-back ratio greater than 5dB. The reading range is up to 0.5 meters.

Feature Summary

• Integrated antenna design for compact installation
• Supports multiple UHF RFID communication standards
• Power over Ethernet connectivity for simplified wiring

Applications

• Short-range item identification
• Automated machine vision integration
• Controlled access point monitoring

Procurement Notes

Verify that the specific application environment falls within the supported UHF frequency bands for the target region. Confirm that the required reading distance does not exceed the maximum 0.5-meter operational limit defined by the integrated antenna specifications. Ensure network infrastructure supports Power over Ethernet requirements for reliable operation.

Selection Notes

Select this model when a fixed, short-range identification solution is required without external antenna cabling. The integrated antenna simplifies mechanical mounting compared to distributed systems. Consider the 110-degree beam width for coverage area planning. This device is suitable for applications where high-speed long-range scanning is unnecessary.

Part Context

This component belongs to the RFU61x product family from SICK, designed for machine vision and identification tasks. The series focuses on robust RFID solutions compatible with industrial automation environments. The RFU610 variant specifically targets short-range applications requiring integrated hardware components.

Replacement Considerations

No public confirmed substitute part numbers are available in the source documentation.
