Product Detailed Parameters
- Description：PCB SOCKET, DOUBLE ROW, 6 PIN, S
- Series：2141
- Mfr：Oupiin
- Package：Bulk
- Connector Type：Socket
- Contact Type：Female Socket
- Style：Board to Board
- Number of Positions：6
- Number of Positions Loaded：All
- Pitch - Mating：0.079" (2.00mm)
- Number of Rows：2
- Row Spacing - Mating：0.079" (2.00mm)
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：Flash
- Insulation Color：Black
- Insulation Height：0.177" (4.50mm)
- Contact Length - Post：0.126" (3.20mm)
- Operating Temperature：-55°C ~ 105°C
- Material Flammability Rating：UL94 V-0
- Contact Finish - Post：Gold
- Mated Stacking Heights：-
- Ingress Protection：-
- Features：-
- Current Rating (Amps)：1A
- Voltage Rating：-
Download product information
Overview
The Oupiin 2141-2X03G00SB is a PCB socket connector designed for through-hole mounting. It features a double-row configuration with six pins, providing a 0.1-inch (2.54mm) pitch. The component utilizes a straight orientation and solder terminals for secure board attachment. Constructed with black insulator material, it ensures reliable electrical connectivity in standard electronic assemblies.
Feature Summary
- Double-row PCB socket design for multi-pin connectivity
- Through-hole mounting method for stable board integration
- Straight orientation with solder terminal construction
Applications
- General-purpose PCB interconnections
- Electronic assembly prototyping
- Industrial control module interfaces
Procurement Notes
Verify the exact pin count and row configuration against official datasheets before procurement. Confirm that the through-hole footprint matches the target PCB layout. Ensure the supplier provides genuine Oupiin components to guarantee contact reliability and insulation resistance specifications are met for the intended application environment.
Selection Notes
Select this connector when a double-row male header interface is required for through-hole applications. Consider the 0.1-inch pitch compatibility with mating female sockets. Evaluate the straight profile constraints within the enclosure design. Verify that the solder terminal type aligns with the manufacturing process capabilities of the production line.
Part Context
This part belongs to the Oupiin series of board connectors, specifically focusing on header and receptacle solutions. It complements other models like the 2011-2X03G00SB by offering a double-row variant. The product line emphasizes standard pitch dimensions and robust mechanical locking features for consistent performance across various electronic systems.
Replacement Considerations
Cross-reference with Oupiin 2011-2X03G00SB for similar pitch requirements. Verify mechanical footprint compatibility before substituting. Ensure mating gender and row configuration match the existing system design to prevent integration issues.
