2143-2X12G00DPU

Overview

The Oupiin 2143-2X12G00DPU is a surface mount board connector featuring a 2.0mm pitch and a dual-row configuration with 24 contacts. Designed as a female socket, it utilizes gold-plated terminals to ensure reliable signal transmission. The component supports a current rating of 1A and incorporates a board guide feature for precise alignment during assembly.

Feature Summary

• Surface mount construction for automated PCB integration
• Dual-row layout providing 24 contact positions
• Gold-plated terminal finish for enhanced conductivity

Applications

• General electronic circuit interconnections
• Consumer device internal wiring
• Industrial control module connections

Procurement Notes

Verify the specific ordering suffix against official Oupiin documentation to confirm pin count and termination style. Ensure compatibility with standard SMD reflow processes. Confirm that the 1A current rating meets the design requirements for the intended application before finalizing procurement.

Selection Notes

Select this component when a low-profile, dual-row interface is required for space-constrained designs. The 2.0mm pitch offers a balance between density and manufacturability. Consider the surface mount orientation and board guide features for assembly efficiency in high-volume production environments.

Part Context

This part belongs to the Oupiin 2143 series, which focuses on 2.0mm pitch header and receptacle solutions. The series provides various configurations including single and dual rows, catering to diverse board-to-board and wire-to-board connectivity needs within the broader Oupiin connector portfolio.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Verify mechanical footprint and electrical specifications carefully if considering alternative vendors.
