Headers, Receptacles, Female Sockets Overview

The Molex 2147210130 is a Zero-Hachi series header connector designed for surface mount applications. It features a right-angle orientation with a 0.80mm pitch and supports 13 circuits in a single row. The contacts utilize matte tin plating to ensure reliable signal transmission. Constructed with a friction lock mechanism, the component secures mating connections effectively. The housing is made of nylon resin, providing structural integrity for PCB interconnections.

Headers, Receptacles, Female Sockets Feature Summary

• Zero-Hachi series design optimized for high-density board-to-board interconnects
• Friction lock mechanism ensures secure mating engagement without additional hardware
• Surface mount right-angle configuration facilitates compact PCB layout integration

Headers, Receptacles, Female Sockets Applications

• High-performance peripheral device interconnections
• Harsh condition electronic assemblies requiring durability
• Compact consumer electronics with space constraints

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific packaging configuration against official distributor catalogs, as tape and reel specifications may vary by region or production batch. Confirm that the matte tin plating variant matches the design requirements for solderability and corrosion resistance in the target application environment before finalizing procurement orders.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a 0.80mm pitch header is required for surface mount technology. Ensure the PCB footprint accommodates the right-angle termination style. Verify that the 13-position capacity aligns with circuit density needs and that the friction lock feature meets the mechanical retention standards for the assembly process.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Molex Zero-Hachi family, which specializes in miniature connectors for portable digital products. The series focuses on miniaturization while maintaining signal integrity. The 2147210130 represents a standard pin count within this lineup, balancing connectivity density with manufacturing ease for modern electronic devices.

Headers, Receptacles, Female Sockets Replacement Considerations

Direct substitutes include other 0.80mm pitch headers from the same manufacturer series. Cross-referencing pin counts and mounting styles is essential. Alternative brands offering similar pitch dimensions require verification of mechanical locking mechanisms and plating compatibility to ensure functional equivalence.
