215391-6

Edgeboard Connectors Overview

The TE Connectivity AMP Connectors part number 215391-6 is a standard card edge connector designed for vertical board-to-board applications. It features a female contact configuration with 13 positions arranged in a single row. The connector utilizes a gold or gold-palladium contact surface finish to ensure reliable signal transmission and corrosion resistance. The pitch between contacts is 0.100 inches (2.54 mm), facilitating compatibility with standard PCB layouts. This component is engineered for high-density interconnect solutions requiring robust mechanical stability and consistent electrical performance in demanding electronic environments.

Edgeboard Connectors Feature Summary

• Vertical board-to-board interconnect design
• Female contact configuration for secure mating
• Gold or gold-palladium contact surface finish
• Single-row layout with 0.100 inch pitch

Edgeboard Connectors Applications

• High-density electronic assemblies
• Industrial control systems
• Telecommunications equipment
• Consumer electronics modules

Edgeboard Connectors Procurement Notes

Verify the exact contact material specification, as sources indicate variations between gold and gold-palladium finishes. Confirm the pin count alignment with the specific application requirement, noting conflicting data regarding 6 versus 13 positions. Ensure the selected variant matches the required voltage and current ratings for the intended circuit. Cross-reference the datasheet for precise mechanical dimensions to guarantee proper fit within the assembly constraints.

Edgeboard Connectors Selection Notes

Select this connector based on the need for a vertical, single-row interface with a 2.54 mm pitch. Consider the contact plating options available, such as gold or gold-palladium, depending on the environmental conditions and wear requirements of the application. Evaluate the mechanical stability provided by the card edge design against the space constraints of the host board. Ensure compatibility with mating connectors that match the specified contact type and row configuration.

Edgeboard Connectors Part Context

This component belongs to the standard card edge connector family from TE Connectivity AMP Connectors. It is designed to provide reliable interconnection between printed circuit boards in various electronic devices. The series offers a balance of density and ease of assembly, making it suitable for applications where vertical stacking or direct board connection is preferred over cable harnesses.

Edgeboard Connectors Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Verify compatibility with existing mating components before considering alternative sources. Consult manufacturer guidelines for any obsolescence notices or recommended upgrades within the same product family.
