2160-A6-S110-0EBGA is listed in the Headers, Receptacles, Female Sockets range at ChipApex. The manufacturer field lists Marutsuelec. Its product description is CONN RCPT 10POS 0.1 PCB R/A. Review the specifications below when checking this part for your BOM.
Headers, Receptacles, Female Sockets specifications for 2160-A6-S110-0EBGA
- Description：CONN RCPT 10POS 0.1 PCB R/A
- Series：-
- Mfr：Marutsuelec
- Package：Bulk
- Connector Type：Receptacle
- Contact Type：Female Socket
- Style：Board to Board or Cable
- Number of Positions：10
- Number of Positions Loaded：All
- Pitch - Mating：0.100" (2.54mm)
- Number of Rows：1
- Row Spacing - Mating：0.100" (2.54mm)
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Finish - Mating：-
- Contact Finish Thickness - Mating：-
- Insulation Color：Black
- Insulation Height：0.335" (8.50mm)
- Contact Length - Post：-
- Operating Temperature：-40°C ~ 105°C
- Material Flammability Rating：UL94 V-0
- Contact Finish - Post：-
- Mated Stacking Heights：-
- Ingress Protection：-
- Features：-
- Current Rating (Amps)：3A
- Voltage Rating：-
Headers, Receptacles, Female Sockets datasheet and documents for 2160-A6-S110-0EBGA
Headers, Receptacles, Female Sockets Overview
The Marutsuelec 2160-A6-S110-0EBGA is a 10-position receptacle connector designed for through-hole mounting. It features a 0.100-inch (2.54mm) pin spacing to ensure compatibility with standard PCB layouts. This component serves as an interface solution within electronic assemblies, providing reliable signal transmission pathways. The connector is engineered for stable mechanical retention and electrical continuity in various circuit applications.
Headers, Receptacles, Female Sockets Feature Summary
- Through-hole mounting configuration for secure PCB attachment
- 10-position receptacle design for multi-signal connectivity
- Standard 0.100 inch (2.54mm) pitch for universal compatibility
Headers, Receptacles, Female Sockets Applications
- General-purpose electronic circuit interconnections
- Development board signal routing
- Industrial control panel wiring interfaces
Headers, Receptacles, Female Sockets Procurement Notes
Verify the specific manufacturer origin, as Marutsuelec acts primarily as a distributor. Confirm that the part number corresponds exactly to the 10-position through-hole receptacle specification. Ensure the supplier provides authentic components with traceable documentation to guarantee performance reliability in final assembly.
Headers, Receptacles, Female Sockets Selection Notes
Select this connector when a 10-pin through-hole interface is required. The 2.54mm pitch ensures alignment with standard header pins. Consider mechanical stability and contact material quality for long-term durability in operational environments requiring consistent signal integrity.
Headers, Receptacles, Female Sockets Part Context
This component belongs to the category of passive electronic connectors. It functions as a physical interface between PCB traces and external cabling or headers. Unlike active semiconductor devices, it provides no signal processing capabilities, serving solely as a conductive pathway for power or data transmission within the system architecture.
