2160-A6-S215-0EBGA

Headers, Receptacles, Female Sockets Overview

The Marutsuelec 2160-A6-S215-0EBGA is a 30-position receptacle connector designed for through-hole PCB mounting. It features a 0.100 inch (2.54 mm) pitch and utilizes right-angle termination to facilitate compact board layouts. The component supports a current rating of 3 Amps and offers a minimum insulator resistance of 1000 Megohms with a maximum contact resistance of 20 milliohms. It withstands AC 600V dielectrically and complies with RoHS standards, ensuring lead-free construction for modern electronic assemblies.

Headers, Receptacles, Female Sockets Feature Summary

• Right-angle through-hole termination for space-efficient PCB integration
• High current capacity rated at 3 Amps per contact
• Low contact resistance ensuring reliable signal transmission
• RoHS compliant lead-free construction

Headers, Receptacles, Female Sockets Applications

• Industrial control system interconnects
• Consumer electronics assembly boards
• General-purpose circuit board connections

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific suffix 'S215' against the manufacturer's official datasheet to confirm pin count and orientation details. Ensure the required 30-position configuration matches the design specification. Confirm RoHS compliance status if environmental regulations apply to the final product assembly. Check for any specific packaging requirements or handling instructions provided in the official documentation.

Headers, Receptacles, Female Sockets Selection Notes

Select this connector when a 30-position right-angle through-hole solution is required. The 0.100 inch pitch ensures compatibility with standard header pins. Consider the 3 Amp current rating for power distribution needs. Verify that the PCB hole layout accommodates the recommended dimensions specified in the technical drawings.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the 2160 series of connectors from Marutsuelec, which are widely used in various electronic applications. The series offers multiple position options and termination styles to suit different design constraints. The 2160-A6 variant specifically denotes the right-angle receptacle configuration within this family.

Headers, Receptacles, Female Sockets Replacement Considerations

Direct substitutes must match the 30-position count, 0.100 inch pitch, and right-angle through-hole termination. Verify mechanical dimensions and current ratings before swapping. Generic equivalents may lack the specific material properties or contact plating of the original component.
