21602X2GSE

Headers, Receptacles, Female Sockets Overview

The Marutsuelec 21602X2GSE is a 2-position receptacle connector designed for through-hole mounting. It features female sockets with a 0.100-inch (2.54mm) pin spacing, ensuring compatibility with standard PCB layouts. The component utilizes a gold-plated contact finish to provide reliable electrical conductivity and corrosion resistance over repeated mating cycles. Constructed with durable materials, it supports secure wire-to-board connections in various electronic assemblies requiring robust interconnect solutions.

Headers, Receptacles, Female Sockets Feature Summary

• Through-hole mounting configuration for stable PCB integration
• Female socket design compatible with standard header pins
• Gold-plated contacts for enhanced signal integrity

Headers, Receptacles, Female Sockets Applications

• General-purpose electronic circuit board interconnections
• Industrial control system wiring harnesses
• Consumer electronics assembly modules

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific manufacturer datasheet for precise mechanical dimensions and material specifications before integration. Confirm that the supplier provides official documentation regarding RoHS compliance and environmental certifications. Ensure the ordering suffix matches the required contact plating and housing color options defined by Marutsuelec to avoid functional mismatches in production environments.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a low-profile, two-position through-hole receptacle is required for fixed interconnect applications. Evaluate the 2.54mm pitch against existing PCB footprint constraints to ensure proper alignment. Consider the mechanical retention strength of the through-hole pins versus surface-mount alternatives if vibration resistance is a critical design factor for the target application environment.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Marutsuelec series of headers and receptacles, specifically designed for general interconnect needs. It serves as a complementary counterpart to male header pins, forming complete connection systems. The product line emphasizes standardized spacing and reliable contact performance for mass-produced electronic devices requiring consistent electrical pathways.

Headers, Receptacles, Female Sockets Replacement Considerations

Direct substitutes must match the 2-position count, 2.54mm pitch, and through-hole termination style. Verify that alternative manufacturers offer identical housing geometry and contact plating thickness to maintain interchangeability without redesigning the PCB layout or tooling.
