21602X30GSE

Headers, Receptacles, Female Sockets Overview

The Marutsuelec 21602X30GSE is a 30-position receptacle connector designed for through-hole mounting. It features a right-angle configuration with a 0.100-inch (2.54mm) pitch, suitable for PCB interconnections. The component utilizes a female socket contact type to ensure secure mating with corresponding pins. This specific part number represents the standard industrial variant within the connector lineup.

Headers, Receptacles, Female Sockets Feature Summary

• Right-angle orientation for space-efficient board layout
• Through-hole termination method for robust mechanical stability
• Female socket contacts for reliable signal transmission

Headers, Receptacles, Female Sockets Applications

• General electronic circuit board interconnections
• Industrial control system hardware assembly
• Consumer electronics internal wiring harnesses

Headers, Receptacles, Female Sockets Procurement Notes

Verify the exact pin count and pitch against design schematics before ordering. Confirm that the right-angle footprint matches the PCB silkscreen and copper pad layout. Ensure the through-hole drill dimensions are compatible with manufacturing capabilities. Cross-reference the manufacturer's latest datasheet to confirm availability of this specific suffix.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a right-angle, 30-pin through-hole interface is required. Consider the physical clearance needed for the angled profile during enclosure design. Evaluate the current carrying capacity requirements against the application load. Compare alternative suppliers if supply chain diversification is necessary for long-term production.

Headers, Receptacles, Female Sockets Part Context

This connector belongs to the broader category of headers and receptacles used in electronic assemblies. It serves as a critical interface point between rigid PCBs and cables or other boards. The 2.54mm pitch is a standard industry metric ensuring compatibility with common pin headers and ribbon cable systems.

Headers, Receptacles, Female Sockets Replacement Considerations

Check for direct cross-references from manufacturers like Molex or Samtec offering identical 30-position right-angle through-hole sockets. Verify that any substitute maintains the same 0.100-inch pitch and female contact configuration to ensure mechanical fit.
