21602X3GSE

$0.55

Description：CONN RCPT 3POS 0.1 PCB
Series：-
Mfr：Marutsuelec
Package：Bulk

SKU:55802ff290c8 Category: Headers, Receptacles, Female Sockets Brand: Marutsuelec

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

21602X3GSE is listed in the Headers, Receptacles, Female Sockets range at ChipApex. The manufacturer field lists Marutsuelec. Its product description is CONN RCPT 3POS 0.1 PCB. Review the specifications below when checking this part for your BOM.

Headers, Receptacles, Female Sockets specifications for 21602X3GSE

Description：CONN RCPT 3POS 0.1 PCB
Series：-
Mfr：Marutsuelec
Package：Bulk
Connector Type：Receptacle
Contact Type：Female Socket
Style：Board to Board or Cable
Number of Positions：3
Number of Positions Loaded：All
Pitch - Mating：0.100" (2.54mm)
Number of Rows：2
Row Spacing - Mating：0.100" (2.54mm)
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Push-Pull
Contact Finish - Mating：-
Contact Finish Thickness - Mating：-
Insulation Color：Black
Insulation Height：-
Contact Length - Post：-
Operating Temperature：-55°C ~ 105°C
Material Flammability Rating：UL94 V-0
Contact Finish - Post：-
Mated Stacking Heights：-
Ingress Protection：-
Features：-
Current Rating (Amps)：1A
Voltage Rating：-

Headers, Receptacles, Female Sockets datasheet and documents for 21602X3GSE

21602X3GSE

Headers, Receptacles, Female Sockets Overview

The Marutsuelec 21602X3GSE is a 3-position receptacle connector designed for through-hole mounting. It features a female socket configuration with a 0.100-inch (2.54mm) pitch. This component serves as an electrical interface point within circuit assemblies, providing reliable connectivity for signal or power transmission across the specified contact count.

Headers, Receptacles, Female Sockets Feature Summary

Provides a secure mechanical and electrical connection for three distinct circuit paths
Designed for standard through-hole PCB integration to ensure stable board attachment

Headers, Receptacles, Female Sockets Applications

General-purpose electronic circuit interconnections
Signal routing in modular hardware assemblies
Power distribution interfaces in low-current applications

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific pin configuration and mating partner compatibility before procurement. Confirm that the through-hole footprint matches the target printed circuit board design requirements. Ensure the selected variant meets the necessary environmental ratings for the intended operating conditions. Cross-reference official datasheets to validate material specifications and termination methods.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a fixed three-contact interface is required for through-hole assembly. Consider the 2.54mm pitch standard for compatibility with common header systems. Evaluate mechanical stability needs against the receptacle form factor. Ensure the application does not exceed the current carrying capacity of the internal contacts.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the series of headers and receptacles manufactured by Marutsuelec. It functions as a passive interconnect element within larger electronic systems. The component complements matching male headers to establish temporary or semi-permanent connections between sub-assemblies or modules.
