21602X4GSE

Headers, Receptacles, Female Sockets Overview

The Marutsuelec 21602X4GSE is a 4-position rectangular connector receptacle designed for through-hole PCB mounting. It features female sockets with a 0.100-inch (2.54mm) pin spacing to ensure standardized alignment with mating headers. The component utilizes a gold-plated contact finish to maintain reliable signal transmission and resist corrosion over time. Constructed with a thermoplastic housing, it provides mechanical stability and electrical insulation for secure interconnections in electronic assemblies.

Headers, Receptacles, Female Sockets Feature Summary

• Four-position female socket configuration for secure header mating
• Through-hole termination method for robust PCB attachment
• Gold-plated contacts ensuring durable conductivity and corrosion resistance

Headers, Receptacles, Female Sockets Applications

• General-purpose electronic circuit board interconnections
• Industrial control system module interfaces
• Consumer electronics assembly point-to-point wiring

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific manufacturer datasheet for precise mechanical dimensions and material specifications before integration. Confirm that the supplier source is an authorized distributor to guarantee component authenticity. Ensure the receiving environment meets storage requirements to prevent contamination of the gold-plated contacts prior to installation.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a low-profile, four-channel interface is required for direct PCB mounting. The 2.54mm pitch ensures compatibility with standard industry header arrays. Consider the through-hole technology requirement for mechanical strength versus surface-mount alternatives. Evaluate the operating temperature range against the specific application environment constraints.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the rectangular connector family manufactured by Marutsuelec. It serves as a passive interconnect element within larger electronic systems. The design focuses on providing a stable physical and electrical link between circuit boards or cables. It represents a standard solution for fixed-position connections in modular hardware designs.
