21602X5GSE is listed in the Headers, Receptacles, Female Sockets range at ChipApex. The manufacturer field lists Marutsuelec. Its product description is CONN RCPT 5POS 0.1 PCB. Review the specifications below when checking this part for your BOM.
Headers, Receptacles, Female Sockets specifications for 21602X5GSE
- Description：CONN RCPT 5POS 0.1 PCB
- Series：-
- Mfr：Marutsuelec
- Package：Bulk
- Connector Type：Receptacle
- Contact Type：Female Socket
- Style：Board to Board or Cable
- Number of Positions：5
- Number of Positions Loaded：All
- Pitch - Mating：0.100" (2.54mm)
- Number of Rows：2
- Row Spacing - Mating：0.100" (2.54mm)
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Finish - Mating：-
- Contact Finish Thickness - Mating：-
- Insulation Color：Black
- Insulation Height：-
- Contact Length - Post：-
- Operating Temperature：-55°C ~ 105°C
- Material Flammability Rating：UL94 V-0
- Contact Finish - Post：-
- Mated Stacking Heights：-
- Ingress Protection：-
- Features：-
- Current Rating (Amps)：1A
- Voltage Rating：-
Headers, Receptacles, Female Sockets datasheet and documents for 21602X5GSE
Headers, Receptacles, Female Sockets Overview
The Marutsuelec 21602X5GSE is a 5-position female socket header connector designed for through-hole mounting. It features a 0.100-inch (2.54mm) pitch, providing standardized spacing for reliable electrical interconnections. The component is classified under headers and receptacles, intended for secure board-to-board or cable-to-board connections in electronic assemblies requiring robust mechanical retention.
Headers, Receptacles, Female Sockets Feature Summary
- Provides five distinct contact positions for signal or power routing
- Utilizes a 0.100 inch (2.54 mm) grid spacing standard
- Engineered for through-hole PCB integration
Headers, Receptacles, Female Sockets Applications
- General-purpose electronic circuit interconnection
- Board-to-board signal transmission modules
- Peripheral device interface connectors
Headers, Receptacles, Female Sockets Procurement Notes
Verify the specific pin count matches the required five-position configuration before integration. Confirm that the through-hole mounting style aligns with the target printed circuit board layout and manufacturing processes. Ensure compatibility with mating male pins regarding pitch and housing dimensions to guarantee proper engagement and electrical continuity.
Headers, Receptacles, Female Sockets Selection Notes
Select this component when a fixed five-connection interface is required within a standard 2.54mm pitch system. It is suitable for applications where through-hole assembly offers superior mechanical stability compared to surface-mount alternatives. Consider the physical footprint constraints on the PCB to ensure adequate clearance for soldering and subsequent assembly steps.
Headers, Receptacles, Female Sockets Part Context
This part belongs to the Marutsuelec series of rectangular connectors, specifically categorized as headers and receptacles. It serves as a passive interconnect solution within the broader portfolio of electronic components used for establishing reliable electrical pathways between discrete boards or cables and main substrates in various hardware configurations.
