21602X6GSE

Headers, Receptacles, Female Sockets Overview

The 21602X6GSE is a rectangular connector receptacle manufactured by Marutsuelec. It features six female socket positions arranged in a single row. The connector utilizes a 0.100-inch (2.54mm) pitch for pin spacing, ensuring compatibility with standard PCB layouts. It is designed for through-hole mounting, providing secure mechanical attachment to the circuit board. The component serves as an interface for wire-to-board or board-to-board connections within electronic assemblies.

Headers, Receptacles, Female Sockets Feature Summary

• Six-position female socket configuration for signal or power transmission
• Standard 0.100 inch (2.54mm) centerline pitch for universal compatibility
• Through-hole termination method for robust PCB integration

Headers, Receptacles, Female Sockets Applications

• General-purpose electronic assembly interconnects
• Industrial control panel wiring interfaces
• Consumer electronics internal module connections

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific contact material and plating finish against project requirements before ordering. Confirm that the housing color and locking mechanism align with the mating header specifications. Ensure the through-hole pad layout matches the footprint defined in the official datasheet to guarantee proper solder joint integrity during assembly processes.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a low-profile, six-channel connection is required on a standard density PCB. The through-hole design offers superior mechanical strength compared to surface-mount alternatives for applications subject to vibration. Ensure the mating header shares the same 2.54mm pitch and gender configuration to maintain reliable electrical continuity.

Headers, Receptacles, Female Sockets Part Context

This part belongs to Marutsuelec's series of rectangular connectors, which are widely used in industrial and commercial electronics. The company specializes in providing reliable interconnect solutions for various form factors. This specific model represents a standard through-hole receptacle option within their broader portfolio of headers and sockets.

Headers, Receptacles, Female Sockets Replacement Considerations

Compatible substitutes must match the 6-position count, 2.54mm pitch, and through-hole termination style. Verify that alternative manufacturers offer identical housing dimensions and contact alignment to ensure interchangeability without modifying the PCB footprint.
