21602X7GSE is listed in the Headers, Receptacles, Female Sockets range at ChipApex. The manufacturer field lists Marutsuelec. Its product description is CONN RCPT 7POS 0.1 PCB. Review the specifications below when checking this part for your BOM.
Headers, Receptacles, Female Sockets specifications for 21602X7GSE
- Description：CONN RCPT 7POS 0.1 PCB
- Series：-
- Mfr：Marutsuelec
- Package：Bulk
- Connector Type：Receptacle
- Contact Type：Female Socket
- Style：Board to Board or Cable
- Number of Positions：7
- Number of Positions Loaded：All
- Pitch - Mating：0.100" (2.54mm)
- Number of Rows：2
- Row Spacing - Mating：0.100" (2.54mm)
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Finish - Mating：-
- Contact Finish Thickness - Mating：-
- Insulation Color：Black
- Insulation Height：-
- Contact Length - Post：-
- Operating Temperature：-55°C ~ 105°C
- Material Flammability Rating：UL94 V-0
- Contact Finish - Post：-
- Mated Stacking Heights：-
- Ingress Protection：-
- Features：-
- Current Rating (Amps)：1A
- Voltage Rating：-
Headers, Receptacles, Female Sockets datasheet and documents for 21602X7GSE
Headers, Receptacles, Female Sockets Overview
The Marutsuelec 21602X7GSE is a 7-position receptacle connector designed for through-hole mounting. It features a female socket configuration with a pin spacing of 0.100 inches (2.54mm). This component serves as an interface connector within electronic assemblies, providing reliable electrical connectivity for signal or power transmission in standard PCB layouts.
Headers, Receptacles, Female Sockets Feature Summary
- Through-hole mounting technology for secure PCB attachment
- Female socket contact configuration for mating with pins
- Standard 0.100 inch (2.54mm) pitch spacing
Headers, Receptacles, Female Sockets Applications
- General-purpose electronic circuit board interconnects
- Signal routing in industrial control modules
- Consumer electronics assembly interfaces
Headers, Receptacles, Female Sockets Procurement Notes
Verify the specific manufacturer datasheet for precise current ratings and voltage specifications before integration. Confirm that the through-hole footprint matches the target PCB design requirements. Ensure compatibility with mating male pin headers regarding pitch and row configuration to guarantee proper mechanical fit and electrical continuity.
Headers, Receptacles, Female Sockets Selection Notes
Select this component when a 7-position female receptacle with 2.54mm pitch is required for through-hole applications. Consider the physical height and housing material properties relative to the enclosure constraints. Evaluate the need for additional locking mechanisms or strain relief features based on the operational environment and vibration levels.
Headers, Receptacles, Female Sockets Part Context
This part belongs to the family of rectangular connectors manufactured by Marutsuelec. It is categorized under headers, receptacles, and female sockets. The product line focuses on standard pitch connectors used for general interconnection needs in various electronic devices and systems.
Headers, Receptacles, Female Sockets Replacement Considerations
Direct substitutes must match the 7-position count, 2.54mm pitch, female socket type, and through-hole mounting style. Verify identical housing dimensions and contact plating specifications to ensure interchangeability without redesigning the PCB footprint.
