21602X8GSE is listed in the Headers, Receptacles, Female Sockets range at ChipApex. The manufacturer field lists Marutsuelec. Its product description is CONN RCPT 8POS 0.1 PCB. Review the specifications below when checking this part for your BOM.
Headers, Receptacles, Female Sockets specifications for 21602X8GSE
- Description：CONN RCPT 8POS 0.1 PCB
- Series：-
- Mfr：Marutsuelec
- Package：Bulk
- Connector Type：Receptacle
- Contact Type：Female Socket
- Style：Board to Board or Cable
- Number of Positions：8
- Number of Positions Loaded：All
- Pitch - Mating：0.100" (2.54mm)
- Number of Rows：2
- Row Spacing - Mating：0.100" (2.54mm)
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Finish - Mating：-
- Contact Finish Thickness - Mating：-
- Insulation Color：Black
- Insulation Height：-
- Contact Length - Post：-
- Operating Temperature：-55°C ~ 105°C
- Material Flammability Rating：UL94 V-0
- Contact Finish - Post：-
- Mated Stacking Heights：-
- Ingress Protection：-
- Features：-
- Current Rating (Amps)：1A
- Voltage Rating：-
Headers, Receptacles, Female Sockets datasheet and documents for 21602X8GSE
Headers, Receptacles, Female Sockets Overview
The Marutsuelec 21602X8GSE is an 8-position receptacle connector designed for through-hole mounting. It features female sockets with a 0.100-inch (2.54mm) pin spacing, ensuring compatibility with standard PCB layouts. The component utilizes a green solder mask finish and is constructed to provide reliable electrical connections in various electronic assemblies.
Headers, Receptacles, Female Sockets Feature Summary
- Through-hole mounting configuration for secure PCB attachment
- Female socket contacts for mating with male pins
- Green solder mask finish for visual identification
Headers, Receptacles, Female Sockets Applications
- General-purpose electronic circuit interconnections
- PCB-to-PCB communication links
- Industrial control system wiring
Headers, Receptacles, Female Sockets Procurement Notes
Verify the specific suffix GSE against official Marutsuelec documentation to confirm the exact color code and packaging specifications. Ensure the through-hole footprint matches the target PCB design before procurement. Cross-reference the 8-position count and 2.54mm pitch with schematic requirements to prevent integration errors during assembly.
Headers, Receptacles, Female Sockets Selection Notes
Select this component when an 8-channel interface with standard 0.100-inch spacing is required. The through-hole technology offers robust mechanical stability compared to surface-mount alternatives. Confirm that the green solder mask variant meets the aesthetic or identification standards of the final product enclosure.
Headers, Receptacles, Female Sockets Part Context
This part belongs to the Marutsuelec header and receptacle series, which provides standardized interconnect solutions. The 21602X8GSE specifically addresses applications needing multiple signal paths in a compact form factor. It is commonly used in consumer electronics and industrial equipment where reliable connectivity is essential.
Headers, Receptacles, Female Sockets Replacement Considerations
Consult official Marutsuelec substitution guides for compatible equivalents. Verify pin count, pitch, and mounting type match exactly before considering alternative suppliers.
