Product Detailed Parameters
- Description：PIN HEADER, SINGLE ROW, 6 PIN, S
- Series：2211
- Mfr：Oupiin
- Package：Bulk
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.050" (1.27mm)
- Number of Positions：6
- Number of Rows：1
- Row Spacing - Mating：-
- Number of Positions Loaded：All
- Style：Board to Board
- Shrouding：Unshrouded
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.110" (2.80mm)
- Contact Length - Post：0.102" (2.60mm)
- Overall Contact Length：0.280" (7.10mm)
- Insulation Height：0.067" (1.70mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：Flash
- Contact Finish - Post：Gold
- Contact Material：Brass
- Insulation Material：Polyamide (PA6T), Nylon 6T
- Features：-
- Operating Temperature：-40°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：1A
- Voltage Rating：-
Download product information
Overview
The Oupiin 2211-1X06G00S/2.6/2.8B is a single-row male pin header featuring six contacts with a 1.27mm (0.05 inch) pitch. Designed for through-hole mounting, this board connector utilizes straight termination and square pin-sleeve contact styling. The component is constructed with high-temperature plastic insulation and meets UL, CUL, and CSA safety certifications. It operates within a temperature range of -40°C to +105°C and includes an insulation height of 1.7mm.
Feature Summary
- Single-row male configuration with square pin-sleeve contacts
- Through-hole straight termination for secure board attachment
- High-temperature plastic housing material
- Certified to UL, CUL, and CSA safety standards
Applications
- Computer peripheral connections
- Communication equipment interfaces
- Industrial control system boards
- General electrical device interconnects
Procurement Notes
Verify the specific suffix codes against official Oupiin documentation to confirm exact physical dimensions and plating specifications. Ensure compatibility with mating socket series before procurement. Cross-reference the manufacturer's latest datasheet to validate current production status and environmental compliance declarations.
Selection Notes
Select this component when a low-profile, single-row interconnect is required for dense circuit layouts. The 1.27mm pitch allows for higher contact density compared to standard 2.54mm headers. Consider the operating temperature range and insulation height requirements to ensure mechanical fit within the target enclosure design constraints.
Part Context
This part belongs to the Oupiin 2211 Series, which specializes in 1.27mm pitch pin headers. The series offers various row counts and termination styles, including surface mount and right-angle options. The 2211 designation indicates the specific 0.05-inch pitch family used across multiple industrial and consumer electronics applications.
Replacement Considerations
Compatible substitutes include other 1.27mm pitch single-row male headers from manufacturers such as Samtec or Molex. Verify that replacement parts match the 6-position count, straight through-hole termination, and similar insulation height specifications.
