2211-2X10G00S-2.6-2.8B

Overview

The Oupiin 2211-2X10G00S-2.6-2.8B is a board connector featuring 20 contacts arranged in two rows with a 2.54mm row spacing. It utilizes a through-hole mounting type and has a current rating of 1A. The operating temperature range spans from -40°C to +105°C. Contact materials include brass, with gold plating on the posts and flash plating for mating surfaces.

Feature Summary

• Through-hole mounting configuration for secure PCB attachment
• Dual-row contact arrangement providing 20 total connections
• Gold-plated posts ensuring reliable electrical conductivity

Applications

• General electronic circuit interconnections
• Industrial control system boards
• Consumer electronics assemblies

Procurement Notes

Verify that the specific suffix designations correspond to the required insulation height and mating dimensions. Confirm compliance with RoHS standards if environmental regulations apply. Ensure the supplier provides original manufacturer documentation to validate authenticity and traceability of the component batch.

Selection Notes

Select this model when a 2.54mm pitch dual-row connector is required for through-hole assembly. Consider the 1A current rating and -40°C to +105°C temperature range against application demands. Verify that the physical dimensions align with the available PCB space and mating partner requirements.

Part Context

This component belongs to the Oupiin 2211 series of board connectors. The series typically offers various contact counts and row configurations. The specific model indicates a 2x10 pin layout with defined mechanical tolerances for standard industrial applications.

Replacement Considerations

Compatible substitutes within the same series may include models with identical 2.54mm pitch and through-hole mounting. Verify that alternative part numbers match the exact contact count and plating specifications before substitution.
